Sensors

PBS-P16

Order no.: 6622
The PBS-P16 is an ultra-precise pressure sensor for up to 16 Bar. It is designed to work with the PowerBox ATOM/CORE, but is also suitable for use with other telemetry systems.
109.00
incl. 19% VAT

Description

Data

Features

Downloads

Description

The robust aluminium case is machined from solid, and contains a small pressure chamber fitted with a digital Mems pressure sensor. The Festo T-connector is simply installed in the existing 4 mm pressure line to the pressure tank. Other pressure hose connections can easily be screwed into the PBS-P16's M5 threaded socket.

The sensor can be connected to various telemetry systems; the system is automatically detected, making the PBS-P16 Plug'n Play

*Futaba will display the pressure value as a temperature as the system cannot show pressure values

Data

Operating voltage 4.0V - 9.0V
Current drain Power-on state max. 20mA
Supported RC systems PowerBox, Jeti, Multiplex, Graupner, Futaba
Dimensions 42 x 17 x 12 mm
Weight 14 g
Temperature range -30°C to +85°C

Features

+ Pressure measurement up to 16 Bar (230 psi)
+ Compact design
+ Low weight
+ Supports the following telemetry systems: PowerBox, P²BUS, Jeti EX-Bus, Multiplex M-Link, Graupner HoTT, Futaba
